Dell PowerConnect 8024 User Guide

Configuring Switching Information 369
Assigning Ports to LAGs and LACPs Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide :
• Port Channel Commands
The following table summarizes the equivalent CLI commands for this feature.
LAG Hash Configuration
Use the LAG HASH algorithm to set the traffic distribution mode on the aggregator link. You can set the
HASH type for each trunk.
To display the LAG Hash Configuration page, click Switching
→ Link Aggregation → LAG Hash
Configuration in the tree view.
Figure 7-71. LAG Hash Configuration
The LAG Hash Configuration page contains the following fields:
• LAG — The drop-down menu lists the LAG numbers.
•
Hash Algorithm Type — The HASH algorithm for unicast traffic flows can be one of the following
types:
– Source MAC, VLAN, EtherType, SourceModule and Port Id
– Destination MAC, VLAN, EtherType, SourceModule and Port Id
Table 7-35. LAG Membership Commands
CLI Command Description
channel-group Associates a port with a port-channel.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
