368 Configuring Switching Information
Figure 7-70. LAG Membership
The LAG Membership page contains a table with the following fields:
• LACP — Aggregates a LAG port to LACP membership. For ports with a number in the LAG row, you
can click in the
LACP row to toggle LACP "on." Each click toggles between L (LACP) and blank (no
LACP).
•
LAG — Adds a port to a LAG, and indicates the specific LAG to which the port belongs. Each click
toggles through the LAG numbers, 1–48, and then back to blank (no LAG assigned).
Adding a Port to a LAG
1. Open the LAG Membership page.
2. Click in the LAG row to toggle the port to the desired LAG.
The LAG number displays for that port. The LAG number increases each time you click until the
number reaches 48 and then returns to blank (no LAG assigned).
3. Click Apply Changes .
The port is assigned to the selected LAG, and the device is updated.
Adding a LAG Port to an LACP
1. Open the LAG Membership page.
2. Click in the LACP row to toggle the desired LAG port to L .
NOTE: The port must be assigned to a LAG before it can be aggregated to an LACP.
3. Click Apply Changes .
The LAG port is aggregated to the LACP, and the device is updated.
