Dell PowerConnect 8024 User Guide

Using Dell™ OpenManage™ Switch Administrator 43
Check Boxes
Defining Fields
User-defined fields can contain 1–159 characters, unless otherwise noted on the Dell OpenManage
Switch Administrator Web page.
All characters may be used except for the following:
•\
•/
•:
•*
•?
•<
•>
•|
Accessing the Switch Through the CLI
The switch can be managed over a direct connection to the console port or through a Telnet connection.
Using the CLI is similar to entering commands on a Linux system. If access is through a Telnet
connection, ensure the device has an IP address defined and that the workstation used to access the
device is connected to the device prior to using CLI commands.
For information about configuring an initial IP Address, see "Configuration Overview."
Table 2-4. Check Boxes
Check Box Type Description
Add Hyperlink that takes you to a configuration page.
Remove Removes the selected item.
General selection To enable a configuration item, i.e., adjust sensitivity of log files, select
match criteria for diffserv, select ACL rule parameters.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
