Configuring IP Multicast 751
Figure 12-30. MLD Proxy Configuration Summary
The MLD Proxy Configuration Summary page contains the following fields:
•
Interface
— Select the interface on which MLD proxy is enabled and for which data is to be displayed.
•
IPv6 Address
— The IPv6 address of the MLD Proxy interface.
•
Prefix Length
— Displays the prefix length for the IPv6 address of the MLD Proxy interface.
•
Admin Mode
— The administrative status of MLD Proxy on the selected interface.
•
Operational Mode
— The operational state of MLD Proxy interface.
•
Number of Multicast Groups
— The current number of multicast group entries for the MLD Proxy
interface in the cache table.
•
Version
— The version of MLD configured on the MLD Proxy interface.
•
Unsolicited Report Interval
— The Unsolicited Report Interval in seconds is the time between
repetitions of a host's initial report of membership in a group.
