Configuring Switching Information 375
• LAGs — Displays and assigns multicast group membership to LAGs. To assign membership, click in
Static for a specific LAG. Each click toggles between S, F, and blank. See the following table for
definitions.
The following table contains definitions for port/LAG IGMP management settings.
Adding Bridge Multicast Addresses
1. Open the Bridge Multicast Group page.
2. Click Add .
The
Add Bridge Multicast Group page displays.
Figure 7-75. Add Bridge Multicast Group
Table 7-39. Port/LAG IGMP Management Settings
Port Control Definition
D Dynamic: Indicates that the port/LAG was dynamically joined to the Multicast group
(displays in the
Current row).
S Static: Attaches the port to the Multicast group as a static member in the
Static row.
Displays in the
Current row once Apply Changes is clicked.
F Forbidden: Indicates that the port/LAG is forbidden entry into the Multicast group in the
Static row. Displays in the Current row once Apply Changes is clicked.
Blank Blank: Indicates that the port is not attached to a Multicast group.
