410 Configuring Switching Information
•
LLDP-MED Mode
— Specifies the Link Layer Data Protocol-Media End Point (LLDP-MED) mode
for the selected interface. Enabling MED effectively enables the transmit and receive function of
LLDP.
•
Config Notification Mode
— Specifies the LLDP-MED topology notification mode for the selected
interface.
•
Transmit TLV s
— Specifies which optional type length values (TLVs) in the LLDP-MED will be
transmitted in the LLDP PDUs frames for the selected interface.
–
MED Capabilities
— To transmit the capabilities TLV in LLDP frames.
–
Network Policy
— To transmit the network policy TLV in LLDP frames.
–
Location Identification
— To transmit the location TLV in LLDP frames.
–
Extended Power via MDI - PSE
— To transmit the extended PSE TLV in LLDP frames.
–
Extended Power via MDI - PD
— To transmit the extended PD TLV in LLDP frames.
–
Inventory
— To transmit the inventory TLV in LLDP frames.
Modifying the LLDP-MED Interface Configuration
1.
Open the
LLDP Configuration
page.
2.
Specify the unit and select a port to configure, or select All to configure all ports with the same
settings.
3.
Configure the LLDP-MED settings for the interface or interfaces
4.
Click
Apply Changes
.
LLDP-MED parameters are saved to the switch.
NOTE: If you configured All ports, the settings you applied will not display after the page updates. Select a specific
interface or click Show All to view interface LLDP-MED settings.
Displaying the Interface Summary
1.
Open the
LLDP-MED Interface Configuration
page.
2.
Click
Show
All
.
The
LLDP-MED Interface Summary
page displays and provides summary LLDP-MED information
for all interfaces:
