Viewing Statistics and Remote Monitoring 457
The Interface Statistics page contains the following fields:
•
Interface
— Select physical interface (unit, port) or LAG interface for which statistics is displayed.
•
Refresh Rate
— Specifies amount of time that passes before statistics are refreshed. The possible field
values are No Refresh, 15, 30 and 60 seconds. Default is No Refresh.
Received Statistics
•
Total Bytes (Octets)
— Displays the total number of octets received on the selected interface.
•
Unicast Packets
— Displays the total number of Unicast packets received on the selected interface.
•
Multicast Packets
— Displays the total number of Multicast packets received on the selected
interface.
•
Broadcast Packets
— Displays the total number of Broadcast packets received on the selected
interface.
•
Packets with Errors
— Displays the total number of packets with errors received on the selected
interface.
Transmit Statistics
•
Total Bytes (Octets)
— Displays the total number of octets transmitted on the selected interface.
•
Unicast Packets
— Displays the total number of Unicast packets transmitted on the selected interface.
•
Multicast Packets
— Displays the total number of Multicast packets transmitted on the selected
interface.
•
Broadcast Packets
— Displays the total number of Broadcast packets transmitted on the selected
interface.
Displaying Interface Statistics
1.
Open the
Interface Statistics
page.
2.
Specify an interface.
Statistics for specified interface display.
Viewing Interface Statistics Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide
:
• Ethernet Configuration Commands
The following table summarizes the equivalent CLI commands for this feature.
Table 8-1. Interface Statistics Commands
CLI Command Description
show interfaces counters Display traffic seen by the interface.
