3. Confirm that the device is connected and operating correctly by examining the LEDs on the front
panel.
For a complete explanation of the LEDs, see LED Definitions
Figure 3-2. AC Power Connection to PowerConnect 8024/8024F
To AC power
source
To AC power
source
