4.8 Impeller Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 22 Isolette® Infant Incubator (Model C2000) Service Manual
4.8 Impeller Assembly
Tools required: Pliers
Removal
SHOCK HAZARD:
Unplug the power cord from the controller assembly. Failure to do so
could result in personal injury or equipment damage.
1. Unplug the power cord from the controller assembly (A) (see figure
4-8 on page 4-22).
Figure 4-8. Impeller Assembly
2. Lift the hood assembly, and carefully tilt it back to its open position.
3. Remove the mattress, the mattress tray, and the x-ray tray from the
unit (refer to procedure 4.7 on page 4-20).
4. Pull the two mattress tilt bars (B) up through the main deck (C), and
remove them from the unit.
5. Remove the main deck (C) from the unit.
To Next Page
