4.26 Access Door Cuff
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 74 Isolette® Infant Incubator (Model C2000) Service Manual
4.26 Access Door Cuff
Tools required: None
Removal
1. Press the access door latch (A), and open the access door (B) (see
figure 4-34 on page 4-74).
Figure 4-34. Access Door Gasket
2. Gently pull the access door cuff (C) from the access door gasket
(D).
Replacement
1. Stretch the larger diameter elastic band of the access door cuff (C)
into the groove in the access door gasket (D).
To Next Page
