Diagnostic Menus
Chapter 2: Troubleshooting Procedures
Page 2 - 48 Isolette® Infant Incubator (Model C2000) Service Manual
Data Summary (2 of 2) Menu
For a description of the information listed on the Data Summary (2 of
2) menu, refer to table 2-13 on page 2-47 (see figure 2-17 on page
2-48).
Figure 2-17. Data Summary Screen (2 of 2)
Table 2-14. Data Summary (2 of 2) Menu
Information Item Description
Long air flow sen-
sor
This displays information no longer applicable to
the operation of the unit.
Short air flow sen-
sor
This displays information no longer applicable to
the operation of the unit.
AC current This displays the instantaneous power consump-
tion of the unit.
Heater thermocou-
ple
This displays the current status of the heater.
O
2
solenoid voltage This displays the current voltage present on the
oxygen solenoid.
