2.32 X-ray Tray Does Not Operate Properly
Chapter 2: Troubleshooting Procedures
Page 2 - 96 Isolette® Infant Incubator (Model C2000) Service Manual
2.32 X-ray Tray Does Not Operate Properly
1. Perform the following:
a. On a unit with a Series 00 hood assembly, slide the blue slide
access panel latches, and open the access panel (see figure 2-2
on page 2-11).
or
On a unit with a hood assembly later than Series 00, rotate the
access panel pawl latch knobs, and open the access panel.
b. Pivot the access panel to the full-open position so it hangs
straight down.
c. Withdraw the x-ray tray (A) (see figure 2-33 on page 2-96).
Figure 2-33. X-ray Tray
d. Return the x-ray tray (A) to its original position.
The problem still exists.
Yes No
↓→Go to “Final Actions” on page 2-24.
2. Inspect the x-ray tray (A). The x-ray tray (A) is free from obstruction.
To Next Page
