Dräger Isolette C2000 - Regulations, Standards, and Codes; Scale Description

Specifications
Chapter 1: Introduction
Isolette® Infant Incubator (Model C2000) Service Manual Page 1 - 15
1
Scale Description
For Isolette® Infant Incubator scale specifications, see table 1-5 on
page 1-15.
Table 1-5. Scale Specifications
Regulations, Standards, and Codes
The Model C2000 Isolette® Infant Incubator meets the following
specifications:
• IEC 601-1
• IEC 601-2-19
• UL-2601
• With respect to the International Electrotechnical Commission (IEC)
601-1, the incubator is Class 1, Type BF.
• On the variable height adjustable model, the mode of operation is
continuous operation with short-time loading.
Feature Dimension
Weight display range 0 kg (0 lb) to 7 kg (15 lb)
Weight display resolution 1 g or 1 oz
Weight display accuracy ± 2 g (0.07 oz) ≤ 2 kg (4.4 lb)
or
± 5 g (0.18 oz) ≥ 5 kg (11 lb)
Weight zeroing limit during infant
weighing
> 3.5 kg (7.7 lb)
