4.21 Impeller Movement Detection Sensor
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 58 Isolette® Infant Incubator (Model C2000) Service Manual
12.Remove the impeller movement detection sensor (G) from the unit
enough to access its connector (I).
13.Disconnect the connector (I) from the cable assembly (J). Do not
allow the cable assembly (J) to slide back into the shell assembly
(K).
14.Remove the impeller movement detection sensor (G) from the unit.
Replacement
1. Connect the impeller movement detection sensor (G) to the cable
assembly (J).
2. Install the impeller movement detection sensor (G) so its flat edge is
parallel with the front of the unit.
CAUTION:
Always replace Nylok®
1
screws; do not reuse them. Equipment
damage could occur.
3. Install a new Nylok® screw (H) to secure the impeller movement
detection sensor (G) to the unit.
4. Using a small screwdriver, tighten the screw (F).
5. Install the impeller assembly (refer to procedure 4.8 on page 4-22).
6. Screw the heater radiator (E) onto the heater assembly (D).
7. Install the heater/impeller cover (C) on the unit.
8. Install the main deck (B) on the unit.
9. Slide the two mattress tilt bars (A) through their openings in the main
deck (B).
10.Install the mattress, the mattress tray, and the x-ray tray on the unit
(refer to procedure 4.7 on page 4-20).
11. Carefully lower the hood assembly to its closed position.
1. Nylok® is a registered trademark of Nylok Fastener Corporation.
