4.8 Impeller Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Isolette® Infant Incubator (Model C2000) Service Manual Page 4 - 23
4
6. Remove the heater/impeller cover (D) from the unit.
7. Using pliers, remove the wire hose clamp (E) that secures the
impeller assembly (F) to the shell assembly (G).
8. Remove the impeller assembly (F) from the shell assembly (G).
Replacement
1. Perform the removal procedure in reverse order.
2. To ensure proper operation of the Isolette® Infant Incubator,
perform the “Function Checks” on page 2-6.
