4.31 Mattress Tilt Knob
Chapter 4: Removal, Replacement, and Adjustment Procedures
Isolette® Infant Incubator (Model C2000) Service Manual Page 4 - 89
4
d. Ensure that the extrusion bumper (H) fits properly between the
shell assembly (B) and the shell bottom (G).
CAUTION:
Always replace Nylok®
1
screws; do not reuse them. Equipment
damage could occur.
7. Install four new Nylok® screws (F) to secure the shell bottom (G) to
the shell assembly (B).
8. If the unit is equipped with an oxygen system, install it (refer to
procedure 7.2 on page 7-8).
9. If the unit is equipped with a humidity system, install it (refer to
procedure 7.3 on page 7-15).
10.Install the heater/impeller cover (E) on the unit (see figure 4-42 on
page 4-84).
11. Install the main deck (D) on the unit.
12.Slide the two mattress tilt bars (C) through their slots in the main
deck (D).
13.Install the mattress, the mattress tray, and the x-ray tray on the unit
(refer to procedure 4.7 on page 4-20).
14.Install the hood assembly on the unit (refer to procedure 4.5 on page
4-14).
15.Install the controller assembly in the shell assembly (refer to
procedure 4.4 on page 4-11).
16.Plug the power cord into the controller assembly (A).
17.To ensure proper operation of the Isolette® Infant Incubator,
perform the “Function Checks” on page 2-6.
1. Nylok® is a registered trademark of Nylok Fastener Corporation.
