6.1 Installation and Set-up
Chapter 6: General Procedures
Isolette® Infant Incubator (Model C2000) Service Manual Page 6 - 13
6
6.1 Installation and Set-up
Tools required: 7/16" socket wrench
Unpacking
NOTE:
Typically, the fixed-height pedestal stand or the optional variable height
adjustable (VHA) pedestal stand and the hood/shell assembly ship in
separate cartons.
CAUTION:
When removing the equipment from the cartons, take care not to
scratch or otherwise damage unprotected surfaces.
1. When removing the equipment from the cartons, take care not to
scratch or otherwise damage unprotected surfaces.
2. Remove all packing materials from the hood/shell assembly (A) (see
figure 6-2 on page 6-15).
Assembling
NOTE:
The hood/shell and the pedestal stand are keyed such that the
hood/shell can mount on the pedestal only when the hood/shell power
cord receptacle is located on the same side as the line cord coming out
of the pedestal/stand.
1. Position the hood/shell assembly (A) on the pedestal stand (B) so
that its power cord receptacle is on the same side as the adapter
power cord (C) of the pedestal stand (B).
