Dräger Isolette C2000 - Key Check Display

Diagnostic Menus
Chapter 2: Troubleshooting Procedures
Isolette® Infant Incubator (Model C2000) Service Manual Page 2 - 45
2
Key Check Display
Perform the following to test the keys at the Key Check display (see
figure 2-15 on page 2-45):
Figure 2-15. Key Check Display
1. Press each key in succession. Each key’s respective box lights.
Yes No
↓→Go to RAP 2.23 on page 2-81.
2. Exit the Key Check display by pressing the Up arrow key (Q) for 3
seconds.
