4.9 Motor Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 24 Isolette® Infant Incubator (Model C2000) Service Manual
4.9 Motor Assembly
Tools required: Phillips head screwdriver
Pliers
Flat, padded surface
Removal
SHOCK HAZARD:
Unplug the power cord from the controller assembly. Failure to do so
could result in personal injury or equipment damage.
1. Unplug the power cord from the controller assembly (A) (see figure
4-9 on page 4-25).
2. Remove the controller assembly from the shell assembly (refer to
procedure 4.4 on page 4-11).
3. Remove the hood assembly from the unit (refer to procedure 4.5 on
page 4-14).
4. Remove the mattress, the mattress tray, and the x-ray tray from the
unit (refer to procedure 4.7 on page 4-20).
5. Remove the impeller assembly from the unit (refer to procedure 4.8
on page 4-22).
6. If the unit is equipped with a humidity system, remove it (refer to
procedure 7.3 on page 7-15).
7. If the unit is equipped with an oxygen system, remove it (refer to
procedure 7.2 on page 7-8).
8. Remove the four Nylok®
1
screws (C) that secure the shell bottom
(D) to the shell assembly (B). Discard the four Nylok® screws (C).
9. Remove the extrusion bumper (E) from between the shell assembly
(B) and the shell bottom (D).
1. Nylok® is a registered trademark of Nylok Fastener Corporation.
