Dräger Isolette C2000 Service Manual

Specifications
Chapter 1: Introduction
Isolette® Infant Incubator (Model C2000) Service Manual Page 1 - 11
1
Specifications
Physical Description
For the physical specifications of the Model C2000 Isolette® Infant
Incubator, see table 1-1 on page 1-11.
Table 1-1. Physical Specifications
Feature Dimension
Height from floor (fixed pedestal stand
model)
56" ± ½" (142 cm ± 12.7 mm)
Height from floor (variable height
adjustable model)
52½" ± ½" to 60" ± ½"
(133.35 cm ± 12.7 mm to
152 cm ± 12.7 mm)
Mattress to floor (fixed pedestal stand
model)
39¾" ± ½" (100.97 cm ±
12.7 mm)
Mattress to floor (variable height
adjustable model)
35½" ± ½" to 43½" ± ½"
(90.17 cm ± 12.7 mm to
110.49 cm ± 12.7 mm)
Depth < 23½" (59.69 cm)
Overall width with tilt knobs < 41" (104 cm)
Weight (fixed pedestal stand model
without options or accessories)
195 lb (88 kg)
Weight (variable height adjustable
model without options or accessories)
200 lb (91 kg)
IV pole maximum static load 10.4 lb (4.7 kg)
Monitor shelf maximum static load 25 lb (11 kg)
Mattress tray width 31" (79 cm)
Mattress tray depth 16" (41 cm)
Mattress Trendelenburg/Reverse
Trendelenburg tilt
Continuously variable to 12°
±1°
Environmental temperature operating
range
68 °F (20 °C) to 86 °F
(30 °C)
Storage temperature -4 °F (-20 °C) to 140 °F
(60 °C)
Air Mode temperature range 68 °F (20 °C) to 98.6 °F
(37.0 °C)
