4.28 Pivot/Hook Lock Assembly Bracket
Chapter 4: Removal, Replacement, and Adjustment Procedures
Isolette® Infant Incubator (Model C2000) Service Manual Page 4 - 79
4
b. Using a small hack saw, remove the marked notch (F) from the
shell assembly (B).
c. Using an emery board, smooth any rough edges of the notch (F).
d. Apply touch-up paint as required.
CAUTION:
Always replace Nylok®
1
screws; do not reuse them. Equipment
damage could occur.
2. Install one or two new Nylok® screws (C) to secure the pivot/hook
lock assembly bracket (D) to the shell assembly (B) (see figure 4-36
on page 4-77).
3. To ensure proper operation of the Isolette® Infant Incubator,
perform the “Function Checks” on page 2-6.
1. Nylok® is a registered trademark of Nylok Fastener Corporation.
