4.15 Electroluminescent (EL) Central Processing Unit (CPU) P.C. Board, EL Display Faceplate, and
EL Display
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 44 Isolette® Infant Incubator (Model C2000) Service Manual
6. Remove the EL display (E) and the four aluminum standoffs (F) from
the EL CPU P.C. board (B) (see “Component Handling” on page
6-8).
Replacement
1. Perform the removal procedure in reverse order.
2. To ensure proper operation of the Isolette® Infant Incubator,
perform the “Function Checks” on page 2-6.
To Next Page
