Electroluminescent Display Front Panel Assembly
Chapter 5: Parts List
Page 5 - 88 Isolette® Infant Incubator (Model C2000) Service Manual
Electroluminescent Display Front Panel Assembly
Figure 5-23. Electroluminescent Display Front Panel Assembly
Table 5-23. Electroluminescent Display Front Panel Assembly
Item Number Part Number Quantity Description
1 83 020 67 1 Front panel subassembly
2 83 009 00 1 Display, electroluminescent (EL), 320
mm wide x 240 mm high
3 83 017 70 1 P.C. board assembly, electrolumines-
cent (EL) central processing unit
(CPU),
Isolette® Infant Incubator
4 99 116 31 4 Standoff, #4-40 thread, ¼" high x
0.56" long, aluminum
5 99 010 90 12 Screw, #4-40 x ¼", pan, phillips, steel,
zinc-plated
