4.33 Sensor Module Lock (Models with Sensor Module Lock Only)
Chapter 4: Removal, Replacement, and Adjustment Procedures
Isolette® Infant Incubator (Model C2000) Service Manual Page 4 - 95
4
Replacement
1. Install the curved spring washer (D) in the slide fixture cover plate
(C).
2. Install the slide lock (E) over the curved spring washer (D).
CAUTION:
Always replace Nylok®
1
screws; do not reuse them. Equipment
damage could occur.
3. From inside the hood assembly (A), install two new Nylok® screws
(B) to secure the slide fixture cover plate (C) to the hood assembly
(A).
4. To ensure proper operation of the Isolette® Infant Incubator,
perform the “Function Checks” on page 2-6.
1. Nylok® is a registered trademark of Nylok Fastener Corporation.
