Dräger Isolette C2000 Service Manual

High Rear Access Panel Assembly (P/N 83 300 71-R) (Series 00 Model Only)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 61
5
Table 5-14. High Rear Access Panel Assembly (P/N 83 300 71-R)
(Series 00 Model Only)
Item Number Part Number Quantity Description
1 83 300 00 1 Access panel, high
2 83 300 05 2 Door, access
3 83 300 11 1 Access door cuff, disposable,
replacement, carton of 100
4 83 300 07 2 Gasket, access door
5 83 300 08 4 Pivot hinge, access door
6 68 510 10 2 Spring, torsion, 0.27" outside diame-
ter, 0.03" wide, 0.365" long
7 83 900 09 2 Replacement kit, access door latch
8 83 300 15 2 Latch mount, access door
9 83 300 26 2 Lower body, access panel latch
10 83 300 25 2 Upper body, access panel latch
11 83 900 08 2 Replacement kit, access panel latch
12 83 300 29 2 Spring, compression, 0.18" outside
diameter, 0.014" wide, 1½" long
13 83 300 33 1 Magnet, ¼" square, 1.00" long, alnico
14 83 300 35 1 Hinge, access panel, left rear
15 83 300 36 1 Hinge, access panel, right rear
16 83 300 09 2 Latch, heat shield
17 83 300 10 2 Hinge, heat shield
18 83 001 10 1 Heat shield, access panel, high
19 99 023 51 2 Screw, #6-32 x 3/8", truss, phillips,
stainless steel, Nylok®
a
a. Nylok® is a registered trademark of Nylok Fastener Corporation.
20 99 088 67 4 Screw, self-tapping, #8 x 3/8", pan,
phillips, steel, zinc-plated, 48-2
21 99 023 64 12 Screw, #6-32 x 7/16", truss, phillips,
stainless steel, Nylok®
22 99 024 19 4 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
23 99 042 66 4 Screw, #10-32 x 5/8", truss, phillips,
stainless steel, Nylok®
