Diagnostic Menus
Chapter 2: Troubleshooting Procedures
Page 2 - 42 Isolette® Infant Incubator (Model C2000) Service Manual
System Test (2 of 3) Menu
The System Test (2 of 3) menu displays the OK/fail results of the
microprocessor’s verification of the operation of the following
components (see figure 2-13 on page 2-42):
Figure 2-13. System Test Menu (2 of 3)
• The sensor module P.C. board
• The humidity EEPROM
• The sensor module fan
• The sensor module analog/digital (A/D) converter
• The sensor module random access memory (RAM)
• The scale load cell
• The scale A/D converter
• The scale’s communication to the unit
