7.3 Humidity System
Chapter 7: Accessories
Isolette® Infant Incubator (Model C2000) Service Manual Page 7 - 15
7
7.3 Humidity System
Tools required: Small screwdriver or similar device
Preparing the Shell Assembly
SHOCK HAZARD:
Unplug the power cord from the unit. Failure to do so could result in
personal injury or equipment damage.
1. Unplug the power cord from the back of the controller (A) (see figure
7-8 on page 7-15).
Figure 7-8. Shell Assembly
2. Lift the hood assembly, and carefully tilt it back to its open position.
3. Remove the mattress, the mattress tray, and the x-ray tray from the
unit (refer to procedure 4.7 on page 4-20).
4. Pull the two mattress tilt bars (B) up through the main deck (C), and
remove them from the unit.
To Next Page
