High Dual Access Hood Assembly with Left & Right Iris Ports (P/N 83 200 77-R)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 15
5
Table 5-3. High Dual Access Hood Assembly with Left & Right Iris Ports
(P/N 83 200 77-R)
Item Number Part Number Quantity Description
1 83 900 59 1 Replacement kit, dual access, iris
ports left and right, pawl
2 83 200 10 1 Hinge, hood/access panel, right front
3 83 200 11 1 Hinge, hood/access panel, left front
4 83 200 12 1 Hinge, hood/access panel, left rear
5 83 200 13 1 Hinge, hood/access panel, right rear
6 83 200 20 10 Grommet, access
7 68 120 76 2 Ring assembly, iris port, large flange
8 68 120 32 2 Ring, retaining, iris port, clear
9 68 120 57 2 Sleeve, iris port, disposable, soft
10 68 232 24 2 Standoff, #6-32 inside diameter, 0.38"
outside diameter, 0.44" long, acety-
lene
11 81 020 20 2 Clamp, cable, spring type, nylon,
0.38" inside diameter
12 99 024 18 2 Screw, #6-32 x 9/16", truss, phillips,
stainless steel
13 99 024 19 2 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
a
14 99 042 92 8 Screw, #10-32 x ¾", truss, phillips,
stainless steel, Nylok®, step bolt
15 83 200 45 2 Slide assembly, sensor module
16 99 105 02 4 Nut, hex, #6-32, stainless steel
17 99 024 52 4 Screw, #6-32 x 5/8", pan, phillips,
stainless steel, Nylok®
18 99 105 20 2 Nut, acorn, #6-32, aluminum
19 83 200 18 2 Plate, backup, hinge, left front and
right rear
20 83 200 19 2 Plate, backup, hinge, left rear and
right front
21 67 502 51 2 Base, screw, ¼"-20, pan
