High Dual Access Hood Assembly with One Access Door and One Iris Port (Series 00 Model)
Chapter 5: Parts List
Page 5 - 28 Isolette® Infant Incubator (Model C2000) Service Manual
Table 5-6. High Dual Access Hood Assembly with One Access Door and
One Iris Port (Series 00 Model Only)
Item Number Part Number Quantity Description
1 83 900 61 1 Replacement kit, dual access, iris port
left, access door left, pawl
2 83 200 15 4 Keeper, access panel latch
3 83 200 10 1 Hinge, hood/access panel, right front
4 83 200 11 1 Hinge, hood/access panel, left front
5 83 200 12 1 Hinge, hood/access panel, left rear
6 83 200 13 1 Hinge, hood/access panel, right rear
7 83 200 20 10 Grommet, access
8 68 120 76 1 Ring assembly, iris port, large flange
9 68 120 32 1 Ring, retaining, iris port, clear
10 68 120 57 1 Sleeve, iris port, disposable, soft
11 83 300 05 1 Door, access
12 81 020 20 2 Clamp, cable, spring type, nylon,
0.38" inside diameter
13 83 300 11 1 Access door cuff, disposable,
replacement, carton of 100
14 83 300 07 1 Gasket, access door
15 83 300 08 2 Pivot hinge, access door
16 68 510 10 1 Spring, torsion, 0.27" outside diame-
ter, 0.030" wide, 0.365" long
17 99 024 19 16 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
a
a. Nylok® is a registered trademark of Nylok Fastener Corporation.
18 83 900 09 1 Replacement kit, access door latch
19 83 300 15 1 Latch mount, access door
20 99 024 43 2 Screw, #6-32 x 5/8", truss, phillips,
stainless steel
21 99 042 92 8 Screw, #10-32 x ¾", truss, phillips,
stainless steel, Nylok®, step bolt
22 83 200 45 2 Slide assembly, sensor module
23 83 200 42 1 Plate, cover, no calibration fixture
24 99 105 02 4 Nut, hex, #6-32, stainless steel
