Dräger Isolette C2000 Service Manual

High Dual Access Hood Assembly with Left & Right Access Doors (P/N 83 200 80-R) (Series 01 Model
Only)
Chapter 5: Parts List
Page 5 - 40 Isolette® Infant Incubator (Model C2000) Service Manual
Table 5-9. High Dual Access Hood Assembly with Left & Right Access
Doors (P/N 83 200 80-R) (Series 01 Model Only)
Item Number Part Number Quantity Description
1 83 200 31 1 Hood, high, dual access, access
doors left and right
2 83 200 10 1 Hinge, hood/access panel, right front
3 83 200 11 1 Hinge, hood/access panel, left front
4 83 200 12 1 Hinge, hood/access panel, left rear
5 83 200 13 1 Hinge, hood/access panel, right rear
6 83 200 20 10 Grommet, access
7 68 232 24 2 Standoff, #6-32 inside diameter, 0.38"
outside diameter, 0.44" long, acety-
lene
8 83 300 05 2 Door, access
9 81 020 20 2 Clamp, cable, spring type, nylon,
0.38" inside diameter
10 83 300 11 1 Access door cuff, disposable,
replacement, carton of 100
11 83 300 07 2 Gasket, access door
12 83 300 08 4 Pivot hinge, access door
13 68 510 10 2 Spring, torsion, 0.27" outside diame-
ter, 0.30" wide, 0.365" long
14 99 024 19 20 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
a
15 83 900 09 2 Replacement kit, access door latch
16 83 300 15 2 Latch mount, access door
17 99 024 18 2 Screw, #6-32 x 9/16", truss, phillips,
stainless steel
18 99 042 92 8 Screw, #10-32 x ¾", truss, phillips,
stainless steel, Nylok®, step bolt
19 99 024 43 4 Screw, #6-32 x 5/8", truss, phillips,
stainless steel
20 99 122 04 4 Washer, flat, 0.15" inside diameter,
0.31" outside diameter, 0.06" thick,
nylon
21 83 200 45 2 Slide assembly, sensor module
