Dräger Isolette C2000 Service Manual

High Front Access Hood Assembly with Left & Right Access Doors (P/N 83 200 74) (Series 00 Model
Only)
Chapter 5: Parts List
Page 5 - 44 Isolette® Infant Incubator (Model C2000) Service Manual
Table 5-10. High Front Access Hood Assembly with Left & Right Access
Doors (P/N 83 200 74) (Series 00 Model Only)
Item Number Part Number Quantity Description
1 83 200 33 1 Hood, high, front access, two access
doors, rear, access door left and right
2 83 200 15 2 Keeper, access panel latch
3 83 200 10 1 Hinge, hood/access panel, right front
4 83 200 11 1 Hinge, hood/access panel, left front
5 83 200 16 1 Hinge, hood, left, rear
6 83 200 17 1 Hinge, hood, right, rear
7 83 300 05 4 Door, access
8 83 300 11 1 Access door cuff, disposable,
replacement, carton of 100
9 83 300 07 2 Gasket, access door
10 83 300 08 4 Pivot hinge, access door
11 68 510 10 2 Spring, torsion, 0.27" outside diame-
ter, 0.30" wide, 0.365" long
12 83 900 09 2 Replacement kit, access door latch
13 83 300 15 2 Latch mount, access door
14 83 200 20 6 Grommet, access
15 68 232 24 2 Standoff, #6-32 inside diameter, 0.38"
outside diameter, 0.44" long, acety-
lene
16 83 001 10 1 Heat shield, access panel, high
17 81 020 20 2 Clamp, cable, spring type, nylon,
0.38" inside diameter
18 99 085 15 8 Screw, self-tapping, #6-32 x 3/8", flat,
truss, phillips, stainless steel
19 99 088 67 2 Screw, self-tapping, #8 x 3/8", pan,
phillips, steel, zinc-plated, 48-2
20 99 023 64 8 Screw, #6-32 x 7/16", truss, phillips,
stainless steel, Nylok®
a
21 99 024 18 1 Screw, #6-32 x 9/16", truss, phillips,
stainless steel
22 99 024 19 16 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
