High Front Access Hood Assembly with Left & Right Access Doors (P/N 83 200 81) (Series 01 Model
Only)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 49
5
21 99 024 19 16 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
a. Nylok® is a registered trademark of Nylok Fastener Corporation.
Item Number Part Number Quantity Description
22 99 042 66 4 Screw, #10-32 x 5/8", truss, phillips,
stainless steel, Nylok®
a
23 99 042 92 8 Screw, #10-32 x ¾", truss, phillips,
stainless steel, Nylok®, step bolt
24 99 105 02 4 Nut, hex, #6-32, stainless steel
25 83 300 09 2 Latch, heat shield
26 83 300 10 2 Hinge, heat shield
27 99 024 43 4 Screw, #6-32 x 5/8", truss, phillips,
stainless steel
28 99 105 20 2 Nut, acorn, #6-32, aluminum
29 99 122 04 4 Washer, flat, 0.15" inside diameter,
0.31" outside diameter, 0.06" thick,
nylon
30 83 200 45 2 Slide assembly, sensor module
31 83 300 36 1 Hinge, access panel, right rear
32 83 300 35 1 Hinge, access panel, left rear
33 99 024 52 4 Screw, #6-32 x 5/8", pan, phillips,
stainless steel, Nylok®
34 83 300 33 1 Magnet, ¼" square, 1.00" long, alnico
35 83 300 04 1 Plate, backup, hinge, heat shield
36 83 200 18 2 Plate, backup, hinge, left front and
right rear
37 83 200 19 2 Plate, backup, hinge, left rear and
right front
38 83 300 13 1 Bracket, heat shield, rear
39 67 502 51 2 Base, screw, ¼"-20, pan
Item Number Part Number Quantity Description
