Dräger Isolette C2000 Service Manual

Replacement High Rear Access Panel Assembly (P/N 83 300 77-R) (Series 01 Model Only)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 65
5
Table 5-15. Replacement High Rear Access Panel Assembly
(P/N 83 300 77-R) (Series 01 Model Only)
Item Number Part Number Quantity Description
1 83 300 52-R 1 Replacement access panel, high
2 83 300 05 2 Door, access
3 83 300 11 1 Access door cuff, disposable,
replacement, carton of 100
4 83 300 07 2 Gasket, access door
5 83 300 08 4 Pivot hinge, access door
6 68 510 10 2 Spring, torsion, 0.27" outside diame-
ter, 0.03" wide, 0.365" long
7 83 900 09 2 Replacement kit, access door latch
8 83 300 15 2 Latch mount, access door
9 83 300 33 1 Magnet, ¼" square, 1.00" long, alnico
10 83 300 35 1 Hinge, access panel, left rear
11 83 300 36 1 Hinge, access panel, right rear
12 83 300 09 2 Latch, heat shield
13 83 300 10 2 Hinge, heat shield
14 83 001 11-R 1 Replacement heat shield, access
panel, pawl
15 99 023 51 2 Screw, #6-32 x 3/8", truss, phillips,
stainless steel, Nylok®
a
a. Nylok® is a registered trademark of Nylok Fastener Corporation.
16 99 088 67 4 Screw, self-tapping, #8 x 3/8", pan,
phillips, steel, zinc-plated, 48-2
17 99 023 64 8 Screw, #6-32 x 7/16", truss, phillips,
stainless steel, Nylok®
18 99 024 19 4 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
19 99 042 66 4 Screw, #10-32 x 5/8", truss, phillips,
stainless steel, Nylok®
20 83 300 04 1 Plate, backup, hinge, heat shield
21 83 300 13 1 Bracket, heat shield, rear
22 83 300 57 2 Spacer, #6-32 inside diameter, 0.31"
outside diameter, ½" long, acetylene
