Shell Assembly (Series 03 Model Only)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 77
5
Table 5-18. Shell Assembly (Series 03 Model Only)
Item Number Part Number Quantity Description
1 99 032 57 5 Screw, #8-32 x 5/8", truss, phillips,
stainless steel, Nylok®
a
2 83 100 11 1 Door, access, pneumatic module
3 68 212 05 1 Label, ground symbol, functional
4 99 055 96 4 Screw, ¼"-20 x ½", truss, phillips,
steel, zinc-plated, Nylok®
5 83 100 02 1 Shell, bottom
6 99 122 04 2 Washer, flat, 0.150" inside diameter,
0.31" outside diameter, 0.06" thick,
nylon
7 99 022 83 2 Screw, #6-32 x ¼", pan, phillips,
stainless steel, sems external
8 83 100 41 1 Door, humidity cover
9 83 100 42 1 Spring, formed, humidity door
10 83 100 16 1 Bracket, pivot, left, painted
11 99 042 08 2 Screw, #10-32 x ½", pan, phillips,
stainless steel, Nylok®
12 99 042 05 2 Screw, #10-32 x ½", truss, phillips,
stainless steel, Nylok®
13 83 100 03 1 Deck, Isolette® Infant Incubator
14 83 110 15 4 Cap, tubing, 1.00" outside diameter,
white acrylonitrile butadiene styrene
(ABS)
15 83 900 11 1 Lift bar kit, Isolette® Infant Incubator
16 83 100 04 1 Cover, scroll
17 20 015 65 1 Clamp, hose (for 3/8" outside diame-
ter)
18 83 102 85 1 Impeller assembly
19 83 102 70-R 1 Bracket, pivot/hood lock assembly
20 83 100 20 2 Extrusion, bumper
21 83 900 16 1 Replacement kit, check valve assem-
bly
22 01 017 00 2 Connector, barb, ¼" hose x 1/8"
National Pipe Thread (NPT) (male)
To Next Page
