Top Shell Assembly (Series 03 Model Only)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 81
5
Table 5-19. Top Shell Assembly (Series 03 Model Only)
Item Number Part Number Quantity Description
1 99 031 53 2 Screw, #8-32 x 3/8", cap, socket,
stainless steel, Nylok®
a
2 83 110 20 2 Knob, mattress tilt
3 83 110 21 2 Shaft, knob
4 99 127 79 2 Washer, flat, 0.516" inside diameter,
0.88" outside diameter, 0.010" thick,
nylon
5 99 182 61 2 Ring, retaining, external “E”, stainless
steel
6 83 100 68 1 Plug, 7/16"-14, UNC-2A, 1.06" long
overall
7 99 024 19 1 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
8 83 102 80 1 Probe, impeller movement detection
9 83 100 48 1 Cable assembly, AC harness to con-
troller
10 83 100 60 1 Wiring harness assembly, AC
11 83 100 53 1 Cable assembly, incubator motor to
controller
12 83 100 49 1 Cable assembly, sensor module to
controller
13 17 683 51 2 Switch, single-pole single-throw
(SPST), normally closed (NC), mag-
netic reed
14 83 100 09 2 Plate, mounting, Hall effect
15 83 100 13 1 Handle, right
16 99 010 67 4 Screw, #4-40 x ¼", truss, phillips,
stainless steel, Nylok®
17 99 105 34 2 Nut, hex, #6-32, keps, steel, zinc-
plated
18 83 900 24 2 Retrofit kit, tilt mechanism
19 99 040 91 6 Screw, #10-32 x 5/16", pan, phillips,
steel, zinc-plated, Nylok®
20 99 122 92 4 Washer, lock, internal, #8, stainless
steel
To Next Page
