Sensor Module Assembly
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 91
5
Table 5-25. Sensor Module Assembly
Item Number Part Number Quantity Description
1 83 005 51 1 Top cover, sensor module
2 83 005 52 1 Bottom cover, sensor module
3 83 005 55 1 Plate, without oxygen, sensor module
4 83 005 30 1 Cable assembly, sensor module
5 17 735 65 1 Strain relief, rectangular, ¼"-0.29"
diameter
6 83 005 32 1 Lens, light-emitting diode (LED),
white, sensor module
7 83 005 46 1 Fan assembly, 40 mm x 40 mm x 10
mm
8 83 005 70 1 P. C. board assembly, sensor module
9 83 004 70 1 P. C. board assembly, connector
board
10 83 003 70 1 P. C. board assembly, humidity board
11 99 023 94 2 Screw, #6-32 x ½", flat, phillips, stain-
less steel
12 99 012 33 4 Screw, #4-40 x 1.00", pan, phillip,
stainless steel
13 83 005 61 1 Label, skin temperature 1
14 83 005 57 1 Label, identification, scale
15 83 005 60 1 Label, skin temperature 2
16 83 005 34 1 Cable assembly, oxygen cell
17 83 005 62 1 Label, skin temperature 1 and 2
18 99 024 98 4 Screw, #6-32 x 15/16", pan, phillips,
Nylok®
a
a. Nylok® is a registered trademark of Nylok Fastener Corporation.
19 99 121 22 2 Washer, flat, #4, 0.37" outside diame-
ter, 0.03" thick, nylon
20 99 901 78 As required
Loctite®
b
adhesive #425, 20 g
b. Loctite® is a registered trademark of Loctite Corporation.
21 99 120 00 2 Washer, tab, #6, 0.24" outside diame-
ter, 0.03" thick, stainless steel
To Next Page
