Variable Height Adjustable Pedestal Stand Assembly
Chapter 5: Parts List
Page 5 - 102 Isolette® Infant Incubator (Model C2000) Service Manual
Table 5-28. Variable Height Adjustable Pedestal Stand Assembly
Item Number Part Number Quantity Description
1 83 401 50-R 1 Foot switch assembly, front
2 83 401 55-R 1 Foot switch assembly, rear
3 83 401 02 1 Plate, upper transition, machining
4 83 400 04 1 Column, lower, variable height adjust-
able (VHA)
5 83 400 03 1 Column, upper, VHA
6 83 400 18 1 Cable assembly, AC top, VHA
7 83 400 01 2 Leg, base, machining
8 83 400 28 1 Caster, swivel, 4.92" diameter, direc-
tional lock
9 83 400 29 3 Caster, swivel, 4.92" diameter, total
lock
10 83 400 15 1 Plate, transition, bottom
11 83 400 20 1 Actuator, 120V (120V model only)
12 83 400 21 1 Actuator, 220V (220V model only)
13 17 AZ 205 1 Cable assembly, AC power cord,
gray, 15 A (120V model only)
14 17 AZ 207 1 Cable assembly, AC power, Verband
Deutsher Elektrotechniker (VDE),
gray, 15 A (240V model only)
15 17 AZ 206 1 Cable assembly, controller power,
VDE, VHA
16 17 733 88 1 Strain relief, straight, adjustable up to
0.40" outside diameter
17 17 BH 213 1 Circuit breaker, double-pole single-
throw (DPST)/single-frequency (SF),
15A, 250/28V
18 17 734 01 1 Clamp, cable, loop type, alumi-
num/case-harden, ¼"
19 17 585 38 1 Filter, line, 115V-250V AC
20 99 023 03 2 Screw, #6-32 x 5/16", truss, phillips,
stainless steel, Nylok®
a
21 99 023 51 1 Screw, #6-32 x 3/8", truss, phillips,
stainless steel, Nylok®
To Next Page
