Dräger Isolette C2000 - Page 412

Check Valve Assembly Replacement Kit (P/N 83 900 16)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 111
5
Table 5-31. Check Valve Assembly Replacement Kit (P/N 83 900 16)
Item Number Part Number Quantity Description
1 83 120 21 1 Body assembly, check valve
2 83 120 16 1 Gasket, body, check valve
3 83 120 10 1 Base, check valve
4 83 120 13 1 Piston, check valve
5 83 120 12 1 Spring, compression, 1.04" outside
diameter, 0.40" wide, 1.00" long
6 68 130 57 1 Diaphragm
7 12 360 00 3 Filter disc
8 83 620 64 4 Clamp, hose, 0.46" to 0.545"
9 83 620 68 18" (46 cm) Sound coat, mounting plate
10 78 467 16 1 Check valve, ¼" National Pipe Thread
(NPT), female in, male out
11 07 023 00 1 Coupling, ¼" hose x ¼" NPT (male),
brass
12 67 355 30 1 Street elbow, 90 , ¼" NPT, brass
13 99 182 82 1 Ring, retaining, internal, ½" diameter,
stainless steel
14 83 120 14 1 Seal, piston, check valve
15 99 026 18 3 Screw, #6-32 x 1¾", flat, phillips,
stainless steel
16 68 130 51 1 Washer, flat, 0.628" inside diameter,
0.88" outside diameter, 0.06" thick,
acetylene
17 01 017 00 1 Connector, barb, ¼" hose x 1/8" NPT
(male)
18 99 901 38 As required
Loctite®
a
screwlock #222
a. Loctite® is a registered trademark of Loctite Corporation.
19 99 182 93 1 Ring, retaining, Wal #5105-6255
20 99 900 26 As required
Tape, pipe joint seal, Teflon®
b
, ½"
b. Teflon® is a registered trademark of E. I. du Pont and de Nemours and Company.
21 83 120 06 1 Plug, ¼" inside diameter hose, 1.00"
long, delrin
