Scale Assembly (P/N 83 600 50)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 113
5
Table 5-32. Scale Assembly (P/N 83 600 50)
Item Number Part Number Quantity Description
1 83 600 51 1 Tray, bottom, scale
2 83 600 52 1 Tray, top, scale
3 83 600 53 1 Subframe, scale
4 83 600 55 2 Load beam, 5 kg
5 83 601 70 1 P.C. board (PCB1) assembly, scale
6 83 600 30 1 Cable assembly, scale
7 83 600 54 1 Clamp, retaining
8 99 901 38 As required
Loctite®
a
screwlock #222
a. Loctite® is a registered trademark of Loctite Corporation.
9 99 030 69 8 Screw, #8-32 x ¼", truss, phillips,
stainless steel
10 83 600 56 1 Shield, P.C. board, scale
11 83 500 46 2 Label, barcode
12 83 600 57 3 Shield, scale
13 83 600 58 2 Shield, spacer
14 17 063 12 1 Tape, conductive, copper, 1.00" wide
15 99 022 83 1 Screw, #6-32 x ¼", pan, phillips,
stainless steel, sems external
16 83 600 59 1 Insulator, mylar, 0.014" thick
17 83 600 60 4 Bushing, Flintab
18 81 020 20 2 Clamp, cable, spring-type, nylon,
0.38" inside diameter
19 99 024 19 2 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
b
b. Nylok® is a registered trademark of Nylok Fastener Corporation.
20 99 105 20 2 Nut, acorn, #6-32, aluminum
To Next Page
