Dräger Isolette C2000 Service Manual

Swivel Drawer Assembly, Small (P/N 83 441 00) and Large (P/N 83 440 00) (Accessory)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 119
5
Table 5-35. Swivel Drawer Assembly, Small (P/N 83 441 00) and Large
(P/N 83 440 00) (Accessory)
Item Number Part Number Quantity Description
1 83 440 01 1 Swivel drawer, large (for use with
large swivel drawer assembly only)
2 83 441 01 2 Swivel drawer, small (for use with
small swivel drawer assembly only)
3 83 440 06 1 Support arm, swivel drawers
4 83 440 05 1 Shaft, swivel drawers
5 83 440 02 1 Tray writing surface
6 83 440 08 1 or 2 Ring, bottom, swivel drawers
7 83 440 07 2 or 3 Ring, top, swivel drawers
8 83 440 09 6 or 10 Spring plunger, 3/8"-16
9 99 057 32 2 Screw, ¼"-20 x 7/8", cap, socket,
stainless steel, Nylok®
a
a. Nylok® is a registered trademark of Nylok Fastener Corporation.
10 83 440 03 1 Spacer, 1¼" inside diameter, 2.00"
outside diameter, 0.49" thick,
acrylonitrile butadiene styrene (ABS)
(for use with small swivel drawer
assembly only)
11 99 127 78 1 Washer, flat, 0.536" inside diameter,
1½" outside diameter, 0.05" thick,
stainless steel
12 99 113 66 1 Nut, hex, castle, ½"-20, stainless
steel, 0.56" thick
13 99 141 71 1 Pin, cotter, 0.060" diameter, 1.00"
long, stainless steel
14 99 055 06 1 Screw, ¼"-20 x 3/8", cap, socket,
stainless steel, Nylok®
15 99 125 71 2 Washer, lock, external, ¼", stainless
steel
16 99 901 38 As required
Loctite®
b
screwlock #222
b. Loctite® is a registered trademark of Loctite Corporation.
17 99 900 69 As required
Lubricant, Dow Corning®
c
#111
c. Dow Corning® is a registered trademark of Dow Corning Corporation.
18 83 500 60 1 Label, load limit, 2 lb/0.91 kg
