Humidity System Assembly (P/N 83 613 70/80/81/90) (Accessory) (Series 02 Model Only)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 127
5
Table 5-37. Humidity System Assembly (P/N 83 613 70/80/81/90)
(Accessory) (Series 02 Model Only)
Item Number Part Number Quantity Description
1 83 613 65-R 1 Reservoir assembly, humidity
2 83 613 01 1 Reservoir, humidity
3 83 613 00 1 Cover, humidity reservoir
4 83 900 58 1 Replacement kit, seals and springs
5 83 613 06 1 Seal, silicone sponge, ¾" outside
diameter
6 83 613 10 1 Spring, compression, 0.360", 0.035"
wide, 0.812" long
7 83 613 21 1 Seal, silicone sponge, 1.380" outside
diameter
8 83 613 68-R 1 Tray assembly, humidity, English/
Spanish/French/German/Italian
9 83 613 02 1 Tray, humidity reservoir
10 83 613 13 1 Door, humidity
11 83 500 06 1 Overlay, humidity drawer, English/
Spanish/French/German/Italian
12 83 500 09 1 Overlay, humidity drawer, Swedish/
Greek
13 99 023 46 2 Screw, #6-32 x 3/8", flat, phillips,
stainless steel, Nylok®
a
14 83 500 34 2 Label, manual reference symbol
15 83 613 23 1 Handle, humidity
16 83 613 24 1 Pin, 3/32" diameter, 2.968" long,
stainless steel
17 83 613 55 1 Replacement kit, evaporator reser-
voir, 120V (for use with 120V model
only)
18 83 613 56 1 Replacement kit, evaporator reser-
voir, 240V (for use with 240V model
only)
19 83 613 57 1 Replacement kit, evaporator reser-
voir, 100V (for use with 100V model
only)
20 83 613 60-R 1 Manifold assembly, humidity
To Next Page
