Evaporator Reservoir Assembly (Accessory) (Series 02 Model Only)
Chapter 5: Parts List
Page 5 - 130 Isolette® Infant Incubator (Model C2000) Service Manual
Table 5-38. Evaporator Reservoir Assembly (Accessory)
(Series 02 Model Only)
Item Number Part Number Quantity Description
1 83 613 25 1 Reservoir, evaporator
2 83 612 35 1 Heater, cartridge, 120V, 100W
3 83 613 27 1 Plate, mounting, evaporator and float
housing
4 83 612 47 1 Cap, evaporator, stainless steel
5 83 612 39 1 Plate, mounting, insulation
6 83 613 32 1 Insulation, evaporator reservoir
7 83 613 40 1 Washer, flat, 2.00" outside diameter,
0.06" thick, polypropylene
8 83 612 42 1 Thermostat, automatic, 125 C
open/75 C closed
9 83 612 43 1 Thermostat, manual reset limiter
(150 C)
10 83 612 38 1 Elbow, 3/8" barb, ¼" National Pipe
Thread (NPT), male, brass
11 83 613 28 1 Gasket, evaporator reservoir
12 99 122 20 1 Washer, lock, external, #6, stainless
steel
13 83 612 30 1 Cable assembly, humidity heater to
AC
14 99 022 17 1 Screw, #6-32 x 1/8", sems external,
socket, stainless steel, cap
15 99 023 03 4 Screw, #6-32 x 5/16", truss, phillips,
stainless steel, Nylok®
a
16 83 613 33 1 Washer, flat, 1.38" outside diameter x
0.88" inside diameter x 0.12" thick, sil-
icone
17 83 610 17 1 Washer, flat, 1.29" outside diameter,
0.88 inside diameter, 0.15" thick,
stainless steel
18 99 901 23 As required
Pipe sealant with Teflon®
b
(Loctite®
c
adhesive #592)
19 99 901 98 As required Sealant, pneumatic/hydraulic, Loc-
tite® #54505
To Next Page
