Oxygen System Assembly (P/N 83 620 60 and 83 621 20/21/22) (Accessory)
Chapter 5: Parts List
Page 5 - 134 Isolette® Infant Incubator (Model C2000) Service Manual
Table 5-39. Oxygen System Assembly (P/N 83 620 60 and
83 621 20/21/22) (Accessory)
Item Number Part Number Quantity Description
1 83 620 30 2 Cell, oxygen
2 83 620 71 1 Oxygen calibration fixture assembly,
locking
3 99 031 99 2 Screw, #8-32 x ½", truss, phillips,
stainless steel, Nylok®
a
4 83 620 45 1 Plate, oxygen cell mounting
5 17 751 37 1 Valve, solenoid, 12V DC, 70 psi, oxy-
gen
6 83 620 60 1 Oxygen control valve assembly,
green, Diameter Indexed Safety Sys-
tem (DISS)
7 83 621 20 1 Oxygen control valve assembly,
green
8 83 621 21 1 Oxygen control valve assembly, white
9 83 621 22 1 Oxygen control valve assembly, blue
10 83 100 11 1 Door, access, pneumatic module
11 83 620 61 1 Regulator, pressure, 40 psi
12 83 620 62 1 Bracket, regulator
13 83 620 63 1 Plate, mounting
14 20 102 10 3 Elbow, 90 , ¼" hose, 1/8" National
Pipe Thread (NPT) (male)
15 83 620 67 1 Block, solenoid mount
16 83 620 69 6" (15 cm) Hose, braided, polyvinyl chloride
(PVC), clear, ¼" inside diameter
17 83 620 64 6 Clamp, hose, 0.460", 0.545" inside
diameter
18 99 900 26 As required
Tape, pipe joint seal, Teflon®
b
, ½"
19 68 230 24 6 Isolator, vibration, 0.44" outside diam-
eter, 0.44" long, 4 lb
20 83 620 40 1 Oxygen hose, green, DISS
21 83 620 41 1 Oxygen hose, green
22 83 620 42 1 Oxygen hose, white
23 83 620 43 1 Oxygen hose, blue
To Next Page
