6.3 Oxygen Concentration Test
Chapter 6: General Procedures
Page 6 - 24 Isolette® Infant Incubator (Model C2000) Service Manual
WARNING:
Oxygen flow rates cannot be used as an accurate indication of oxygen
concentration in an incubator. Continuously monitor the oxygen
concentrations with a calibrated oxygen analyzer. Failure to do so could
result in personal injury or equipment damage.
NOTE:
An oxygen concentration guide is provided in table 6-5 on page 6-24.
This guide also appears on the back of the incubator.
4. Apply oxygen at the flow rates described in the oxygen
concentration guide (see table 6-5 on page 6-24).
Table 6-5. Oxygen Concentration Guide
5. To ensure proper operation of the Isolette® Infant Incubator,
perform the “Function Checks” on page 2-6.
Oxygen Supply Approximate Oxygen %
3 lpm 30%-45%
6 lpm 40%-60%
9 lpm 45%-75%
12 lpm 50%-85%
15 lmp 60%-90%
