7.3 Humidity System
Chapter 7: Accessories
Page 7 - 20 Isolette® Infant Incubator (Model C2000) Service Manuall
6. Reach into the humidity cavity, and turn the thumbscrews (AD) on
the humidity manifold assembly (AB) two counterclockwise turns to
secure the humidity manifold assembly (AB). Ensure that the
humidity manifold assembly (AB) is secured.
CAUTION:
To prevent damage to the collar that secures the evaporator assembly
to the shell assembly, be careful not to twist the evaporator assembly
around the horizontal axis when installing its tubing.
7. Connect the tubing (AE) from the evaporator assembly (V) to the
barb fitting (AF) on the humidity manifold assembly (AB). Do not
twist the evaporator assembly (V) around the horizontal axis.
8. Mount the humidity reservoir (AG) and its lid (AH) provided on the
humidity tray (AI) provided.
9. Slide the end of the humidity tray (AI) into the shell assembly (K).
CAUTION:
To prolong the useful life of the humidity system, use only distilled
water. Sterile water is not an acceptable substitute for distilled water.
Equipment damage could occur.
10.Fill the humidity reservoir (AG) with distilled water (refer to
procedure 6.7 on page 6-34).
11. Slide the humidity tray (AI) completely into the shell assembly (K),
and lock the handle (AJ).
12.Screw the heater radiator (E) onto the heater assembly (F) (see
figure 7-8 on page 7-15).
13.Install the heater/impeller cover (D) and the main deck (C) on the
unit.
14.Slide the two mattress tilt bars (B) through their slots in the main
deck (C).
15.Install the mattress, the mattress tray, and the x-ray tray on the unit
(refer to procedure 4.7 on page 4-20).
16.Carefully lower the hood assembly to its closed position.
