Chapter 3 Image Quality Troubleshooting
3.5 Image Quality FIP
3-15
FIP-P2 "All black"
P2
Phenomenon/Initial check Print sample
Print-out is black.
No data is printed out, and paper is all black.
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt or foreign object?
- Major check parts -
AZUSA HVPS (PL9.1.6), ROS ASSY (PL10.1.1), Drum/
toner cartridge (PL10.1.2)
Item Check
Action
(at occurrence of error)
1
- High-pressure spring error -
Is the high-pressure spring transformed or damaged?
Check FIP-2.8 [AZUSA HVPS
error].
2
- ROS ASSY error -
Does the ROS ASSY run normally?
Check FIP-2.2 [ROS ASSY error].
3
- Drum/toner cartridge error -
Doesn't this error recur after the defective Drum/toner
cartridge is replaced with a new one?
Replace the Drum/toner
cartridge.
To Next Page
