Chapter 3 Image Quality Troubleshooting
3.1 Image Troubleshooting
3-2
NOTE
Troubleshooting in this manual assumes use of Diag. tools (maintenance tools).
However, the troubleshooting allows for the case where the Diag tools are not used.
You can correct troubles according to these troubleshooting procedures after
understanding them well.
3.1 Image Troubleshooting
KON301C
Replace Drum/toner cartridge then FUSER ASSY.
The trouble is restored?
End End
The trouble is restored?
Carry out the corresponding troubleshooting.
Start
Teat Printing
Is there a corresponding FIP?
No
Yes
No No
Yes Yes
