Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-34
FIP-2.8 AZUSA HVPS error
Procedure Check
Action
YES NO
1
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt, or foreign object?
- Major check parts -
AZUSA HVPS (PL9.1.6), CABLE HV (PL9.1.8), PWBA
MCU XFABK(B) (PL9.1.25)
Replace and
reattach the parts.
To step 2
2
- CABLE HV check -
Is the CN201<=>J201 connected normally?
To step 3
Replace the
CABLE HV
3
- PWBA MCU XFABK(B) replacement check -
Does this error recur after the defective PWBA MCU
XFABK(B) is replaced with a normal one?
Replace the
AZUSA HVPS
Action completed
