Chapter 6 General
6.5 Installation Procedure
6-21
6.5.4 Loading Paper in Paper Tray
This section explains how to load A4 size plain paper in the landscape orientation in the paper
tray.
1. Hold the paper tray with both hands and pull it
out gently by lifting up the tray slightly.
2. Place the paper tray on a flat surface and
remove the lid.
3. Raise up the width guide lock lever, and then
slide the width guides to the desired paper size.
4. Squeeze the length guide and slide it to the
desired paper size.
Portrait orientation Landscape orientation
To Next Page
