Chapter 10 Machine Overview
10.5 Functions of Major Components
10-17
10.5.4.2 Reference Figure [Fuser & Paper Exit]
SENSOR EXIT
SEPARATOR
pinch roll
ROLL ASSY EXIT
SENSOR ACTUATOR
PRESSURE ROLL
HEAT ROLL
AZS528C
